iAqua Shipborne Mobile Mapping 3D LiDAR System With 500,000 Pts/Sec Scan Rate

iAqua Shipborne Mobile Mapping 3D LiDAR System With 500,000 Pts/Sec Scan Rate

  • iAqua Shipborne Mobile Mapping 3D LiDAR System With 500,000 Pts/Sec Scan Rate
  • iAqua Shipborne Mobile Mapping 3D LiDAR System With 500,000 Pts/Sec Scan Rate
iAqua Shipborne Mobile Mapping 3D LiDAR System With 500,000 Pts/Sec Scan Rate
Product Details:
Place of Origin: China
Brand Name: Hi-Cloud
Certification: ISO, others upon the requests
Model Number: iAqua Ship borne 3D LiDAR Mobile Mapping System
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Transport Case
Delivery Time: 30 working days
Payment Terms: T/T
Supply Ability: 5 sets/month
Contact Now
Detailed Product Description
Number Of Scanners: 1 Measurement Range: Above Water:450m/650m/1200m(Optional)
Scan Rate: Max. 500,000 Pts/sec Scan FoV Horizontal: 360°
Scan FoV Vertical: 100° System Accuracy: Above Water:15cm@100m
High Light:

Mobile Mapping 3D LiDAR System

,

Shipborne 3D LiDAR System

,

Shipborne mobile lidar mapping

450m/650m/1200m range 15cm@100m accuracy iAqua Ship borne 3D LiDAR Mobile Mapping System with 500,000 pts/sec scan rate



The iAqua shipborne above water and underwater integrated 3D mobile measurement system creatively highly integrated light detection and ranging equipment (LiDAR), Global Navigation Satellite System (GNSS), Inertial measurement unit (IMU), 360° panoramic camera, assembly control module and high-performance computer and encapsulated into a rigid platform, the system can also integrate a multi-beam bathymetry module to quickly obtain high-precision positioning and orientation data, high-density 3D point clouds above water, high-definition continuous panoramic images and underwater multi-beam data while moving. Through the data processing, massive data management and application service software equipped with the system, it provides users with a fast, maneuverable and flexible integrated 3D mobile measurement solution for above water and underwater, which can easily complete the application of above water and underwater topographic surveying and mapping, 3D geographic data and real scenes Data production.



Parameters of iAqua Ship borne 3D Laser Mobile Mapping System



Model iAqua
Number of Scanners 1
Measurement Range

Above water:450m/650m/1200m(Optional)

Underwater: Compatible with various brands and models of bathymetry module /multi-beams

Scan Rate Max. 500,000 pts/sec
Scan FoV 360° * 100°(horizontal×vertical)
Panoramic Camera Ladybug/ HD camera(Optional)
Panoramic Resolution 30M/75M pixels
System Accuracy Above water:15cm@100m


Application Fields of iAqua Ship borne 3D Laser Mobile Mapping System



Water area (river courses, lakes, reservoir areas, coastal zones, islands and reefs, waterways) surveying and mapping, river/port/coast facilities survey and dynamic monitoring, digital water conservancy, digital waterway, digital ocean, etc.



Features of iAuqa Ship borne 3D Laser Mobile Mapping System





1. Integration: high integration of multiple sensors



2. Calibration-free: high-precision integrated rigid platform



3. High precision: high measurement accuracy



4. High reliability: stable and reliable system



5. Easy to install: no need to modify the carrier



6. Same benchmark: unified benchmark for above water and underwater


Application of River and Reservoir Survey

iAqua Shipborne Mobile Mapping 3D LiDAR System With 500,000 Pts/Sec Scan Rate 0
